I/O PORTS
S3C2440A RISC MICROPROCESSOR
9-8
I/O PORT CONTROL REGISTER
PORT A CONTROL REGISTERS(GPACON, GPADAT)
Register Address
R/W
Description
Reset
Value
GPACON
0x56000000
R/W
Configures the pins of port A
0xffffff
GPADAT
0x56000004
R/W
The data register for port A
Undef.
Reserved 0x56000008 - Reserved
Undef
Reserved 0x5600000c - Reserved
Undef
GPACON Bit
Description
GPA24 [24]
reserved
GPA23 [23]
reserved
GPA22
[22]
0 = Output
1 = nFCE
GPA21
[21]
0 = Output
1 = nRSTOUT
GPA20
[20]
0 = Output
1 = nFRE
GPA19
[19]
0 = Output
1 = nFWE
GPA18
[18]
0 = Output
1 = ALE
GPA17
[17]
0 = Output
1 = CLE
GPA16
[16]
0 = Output
1 = nGCS[5]
GPA15
[15]
0 = Output
1 = nGCS[4]
GPA14
[14]
0 = Output
1 = nGCS[3]
GPA13
[13]
0 = Output
1 = nGCS[2]
GPA12
[12]
0 = Output
1 = nGCS[1]
GPA11
[11]
0 = Output
1 = ADDR26
GPA10
[10]
0 = Output
1 = ADDR25
GPA9
[9]
0 = Output
1 = ADDR24
GPA8
[8]
0 = Output
1 = ADDR23
GPA7
[7]
0 = Output
1 = ADDR22
GPA6
[6]
0 = Output
1 = ADDR21
GPA5
[5]
0 = Output
1 = ADDR20
GPA4
[4]
0 = Output
1 = ADDR19
GPA3
[3]
0 = Output
1 = ADDR18
GPA2
[2]
0 = Output
1 = ADDR17
GPA1
[1]
0 = Output
1 = ADDR16
GPA0
[0]
0 = Output
1 = ADDR0
