S3C2440A RISC MICROPROCESSOR CAMERA INTERFACE
23-4
Table 23-2 Video Timing Reference Codes of ITU-656 Format
Data bit number First word Second word Third word Fourth word
9 (MSB) 1 0 0 1
8 1 0 0 F
7 1 0 0 V
6 1 0 0 H
5 1 0 0 P3
4 1 0 0 P2
3 1 0 0 P1
2 1 0 0 P0
1 (NOTE) 1 0 0 0
0 1 0 0 0
For compatibility with existing 8-bit interfaces, the values of bits D1 and D0 are not defined.
F = 0 (during field 1), 1 (during field 2)
V = 0 (elsewhere), 1 (during field blanking)
H = 0 (in SAV: Start of Active Video), 1 (in EAV: End of Active Video)
P0, P1, P2, P3 = protection bit
Camera interface logic can catch the video sync bits like H (SAV, EAV) and V (Frame Sync) after reserved data as
“FF-00-00”.
NOTE : All external camera interface IOs are recommended to be Schmitt-trigger type IO for noise reduction.
