S3C2440A RISC MICROPROCESSOR CAMERA INTERFACE
23-19
CODEC MAIN-SCALER CONTROL REGISTER
Register Address R/W Description Reset Value
CICOSCCTRL 0x4F000058 RW Codec main-scaler control 0
CICOSCCTRL Bit Description Initial State
ScalerBypass_Co [31]
Codec scaler bypass for upper 2048 x 2048 size (In this case,
ImgCptEn_CoSC and ImgCptEn_PrSC should be 0, but ImgCptEn
should be 1. It is not allowed to capture preview image. This mode
is intended to capture JPEG input image for DSC application) In
this case, input pixel buffering depends on only input FIFOs, so the
system bus should be not busy in this mode.
0
ScaleUpDown_Co [30:29]
Scale up/down flag for codec scaler
(In 1:1 scale ratio, this bit should be “1”)
00 = down 11 = up
00
MainHorRatio_Co [24:16] Horizontal scale ratio for codec main-scaler 0
CoScalerStart [15] Codec scaler start 0
MainVerRatio_Co [8:0] Vertical scale ratio for codec main-scaler 0
CODEC DMA TARGET AREA REGISTER
Register Address R/W Description Reset Value
CICOTAREA 0x4F00005C RW Codec scaler target area 0
CICOTAREA Bit Description Initial State
CICOTAREA [25:0] Target area for codec DMA = Target H size x Target V size 0
