PWM TIMER S3C2440A RISC MICROPROCESSOR
10-12
TIMER CONFIGURATION REGISTER1 (TCFG1)
Register Address R/W Description Reset Value
TCFG1 0x51000004 R/W 5-MUX & DMA mode selecton register 0x00000000
TCFG1 Bit Description Initial State
Reserved [31:24] 00000000
DMA mode [23:20] Select DMA request channel
0000 = No select (all interrupt) 0001 = Timer0
0010 = Timer1 0011 = Timer2
0100 = Timer3 0101 = Timer4
0110 = Reserved
0000
MUX 4 [19:16] Select MUX input for PWM Timer4.
0000 = 1/2 0001 = 1/4 0010 = 1/8
0011 = 1/16 01xx = External TCLK1
0000
MUX 3 [15:12] Select MUX input for PWM Timer3.
0000 = 1/2 0001 = 1/4 0010 = 1/8
0011 = 1/16 01xx = External TCLK1
0000
MUX 2 [11:8] Select MUX input for PWM Timer2.
0000 = 1/2 0001 = 1/4 0010 = 1/8
0011 = 1/16 01xx = External TCLK1 0000
MUX 1 [7:4] Select MUX input for PWM Timer1.
0000 = 1/2 0001 = 1/4 0010 = 1/8
0011 = 1/16 01xx = External TCLK0 0000
MUX 0 [3:0] Select MUX input for PWM Timer0.
0000 = 1/2 0001 = 1/4 0010 = 1/8
0011 = 1/16 01xx = External TCLK0 0000
