THUMB INSTRUCTION SET S3C2440A RISC MICROPROCESSOR
4-14
Table 4-6. Summary of Format 5 Instructions (Continued)
Op H1 H2 THUMB assembler ARM equivalent Description
01 1 1 CMP Hd, Hs CMP Hd, Hs Compare two registers in the range
8-15. Set the condition code flags on
the result.
10 0 1 MOV Rd, Hs MOV Rd, Hs Move a value from a register in the
range 8-15 to a register in the range 0-
7.
10 1 0 MOV Hd, Rs MOV Hd, Rs Move a value from a register in the
range 0-7 to a register in the range
8-15.
10 1 1 MOV Hd, Hs MOV Hd, Hs Move a value between two registers in
the range 8-15.
11 0 0 BX Rs BX Rs Perform branch (plus optional state
change) to address in a register in the
range 0-7.
11 0 1 BX Hs BX Hs Perform branch (plus optional state
change) to address in a register in the
range 8-15.
INSTRUCTION CYCLE TIMES
All instructions in this format have an equivalent ARM instruction as shown in Table 4-6. The instruction cycle
times for the THUMB instruction are identical to that of the equivalent ARM instruction.
THE BX INSTRUCTION
BX performs a Branch to a routine whose start address is specified in a Lo or Hi register.
Bit 0 of the address determines the processor state on entry to the routine:
Bit 0 = 0 Causes the processor to enter ARM state.
Bit 0 = 1 Causes the processor to enter THUMB state.
NOTE
The action of H1 = 1 for this instruction is undefined, and should not be used.
