LCD CONTROLLER S3C2440A RISC MICROPROCESSOR
15-18
16BPP Display
(BSWP = 0, HWSWP = 0)
D[31:16] D[15:0]
000H P1 P2
004H P3 P4
008H P5 P6
...
(BSWP = 0, HWSWP = 1)
D[31:16] D[15:0]
000H P2 P1
004H P4 P3
008H P6 P5
...
P1 P2 P3 P4 P5
......
LCD Panel
VD Pin Descriptions at 16BPP
(5:6:5)
VD 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RED 4 3 2 1 0
GREEN 5 4 3 2 1 0
BLUE
NC NC
4 3 2 1 0
NC
(5:5:5:I)
VD 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RED 4 3 2 1 0 I
GREEN 4 3 2 1 0
I
BLUE
NC NC
4 3 2 1 0 I
NC
NOTE
The unused VD pins can be used as GPIO
