LCD CONTROLLER S3C2440A RISC MICROPROCESSOR
15-20
4BPP Display
(BSWP = 0, HWSWP = 0)
D[31:28] D[27:24] D[23:20] D[19:16] D[15:12] D[11:8] D[7:4] D[3:0]
000H P1 P2 P3 P4 P5 P6 P7 P8
004H P9 P10 P11 P12 P13 P14 P15 P16
008H P17 P18 P19 P20 P21 P22 P23 P24
...
(BSWP = 1, HWSWP = 0)
D[31:28] D[27:24] D[23:20] D[19:16] D[15:12] D[11:8] D[7:4] D[3:0]
000H P7 P8 P5 P6 P3 P4 P1 P2
004H P15 P16 P13 P14 P11 P12 P9 P10
008H P23 P24 P21 P22 P19 P20 P17 P18
...
2BPP Display
(BSWP = 0, HWSWP = 0)
D [31:30] [29:28] [27:26] [25:24] [23:22] [21:20] [19:18] [17:16]
000H P1 P2 P3 P4 P5 P6 P7 P8
004H P17 P18 P19 P20 P21 P22 P23 P24
008H P33 P34 P35 P36 P37 P38 P39 P40
...
D [15:14] [13:12] [11:10] [9:8] [7:6] [5:4] [3:2] [1:0]
000H P9 P10 P11 P12 P13 P14 P15 P16
004H P25 P26 P27 P28 P29 P30 P31 P32
008H P41 P42 P43 P44 P45 P46 P47 P48
...
