PRODUCT OVERVIEW
S3C2440A RISC MICROPROCESSOR
1-26
Table 1-3. S3C2440A Signal Descriptions (Sheet 6 of 6)
Signal Input/Output
Description
Power
VDDalive
P
S3C2440A reset block and port status register VDD.
It should be always supplied whether in normal mode or in Sleep mode.
VDDiarm
P
S3C2440A core logic VDD for ARM core.
VDDi
P
S3C2440A core logic VDD for Internal block.
VSSi/VSSiarm
P
S3C2440A core logic VSS
VDDi_MPLL
P
S3C2440A MPLL analog and digital VDD.
VSSi_MPLL
P
S3C2440A MPLL analog and digital VSS.
VDDOP
P
S3C2440A I/O port VDD(3.3V)
VDDMOP
P
S3C2440A Memory I/O VDD
3.3V : SCLK up to 135MHz
2.5V : SCLK up to 135MHz
1.8V : SCLK up to 93MHz
VSSOP
P
S3C2440A I/O port VSS
RTCVDD
P
RTC VDD (3.0V, Input range: 1.8 ~ 3.6V)
This pin must be connected to power properly if RTC isn't used.
VDDi_UPLL
P
S3C2440A UPLL analog and digital VDD
VSSi_UPLL
P
S3C2440A UPLL analog and digital VSS
VDDA_ADC
P
S3C2440A ADC VDD(3.3V)
VSSA_ADC
P
S3C2440A ADC VSS
NOTE:
1. I/O means Input/Output.
2. AI/AO means analog input/analog output.
3. ST means schmitt-trigger.
4. P means power.
