INTERRUPT CONTROLLER
S3C2440A RISC MICROPROCESSOR
14-18
INTERRUPT SUB MASK (INTSUBMSK) REGISTER
This register has 11 bits each of which is related to an interrupt source. If a specific bit is set to 1, the interrupt
request from the corresponding interrupt source is not serviced by the CPU (note that even in such a case, the
corresponding bit of the SUBSRCPND register is set to 1). If the mask bit is 0, the interrupt request can be
serviced.
Register Address
R/W
Description
Reset
Value
INTSUBMSK
0X4A00001C
R/W Determine which interrupt source is masked. The
masked interrupt source will not be serviced.
0 = Interrupt service is available.
1 = Interrupt service is masked.
0xFFFF
INTSUBMSK Bit
Description
Initial
State
Reserved [31:15]
Not
used
0
INT_AC97
[14]
0 = Service available, 1 = Masked
1
INT_WDT
[13]
0 = Service available, 1 = Masked
1
INT_CAM_P
[12]
0 = Service available, 1 = Masked
1
INT_CAM_C
[11]
0 = Service available, 1 = Masked
1
INT_ADC_S
[10]
0 = Service available, 1 = Masked
1
INT_TC
[9]
0 = Service available, 1 = Masked
1
INT_ERR2
[8]
0 = Service available, 1 = Masked
1
INT_TXD2
[7]
0 = Service available, 1 = Masked
1
INT_RXD2
[6]
0 = Service available, 1 = Masked
1
INT_ERR1
[5]
0 = Service available, 1 = Masked
1
INT_TXD1
[4]
0 = Service available, 1 = Masked
1
INT_RXD1
[3]
0 = Service available, 1 = Masked
1
INT_ERR0
[2]
0 = Service available, 1 = Masked
1
INT_TXD0
[1]
0 = Service available, 1 = Masked
1
INT_RXD0
[0]
0 = Service available, 1 = Masked
1
