CLOCK & POWER MANAGEMENT

S3C2440A RISC MICROPROCESSOR

-2

FUNCTIONAL DESCRIPTION

CLOCK ARCHITECTURE

Figure 7-1 shows a block diagram of the clock architecture. The main clock source comes from an external crystal
(XTIpll) or an external clock (EXTCLK). The clock generator includes an oscillator (Oscillation Amplifier), which is
connected to an external crystal, and also has two PLLs (Phase-Locked-Loop), which generate the high frequency
clock required in the S3C2440A.

CLOCK SOURCE SELECTION

Table 7-1 shows the relationship between the combination of mode control pins (OM3 and OM2) and the selection
of source clock for the S3C2440A. The OM[3:2] status is latched internally by referring the OM3 and OM2 pins at
the rising edge of nRESET.

Table 7-1. Clock Source Selection at Boot-Up

Mode OM[3:2]

MPLL State

UPLL State

Main Clock source

USB Clock Source

00 On On

Crystal

01 On On

Crystal

EXTCLK

10 On On

EXTCLK

Crystal

11 On On

EXTCLK

NOTE

1. Although the MPLL starts just after a reset, the MPLL output (Mpll) is not used as the system clock until the software

writes valid settings to the MPLLCON register. Before this valid setting, the clock from external crystal or EXTCLK source

will be used as the system clock directly. Even if the user does not want to change the default value of MPLLCON

2. OM[3:2] is used to determine a test mode when OM[1:0] is 11.
