Samsung S3C2440A User Manual
Page 379

S3C2440A RISC MICROPROCESSOR
LCD CONTROLLER
15-11
16 BPP Color mode
16 bits (5 bits of red, 6 bits of green, 5 bits of blue) of video data correspond to 1 pixel. But, stn controller will use
only 12 bit color data. It means that only upper 4bit each color data will be used as pixel data ( R[15:12], G[10:7],
B[4:1]). The following table shows color data format in words:
RGB order
DATA [31:28] [27:21] [20:16] [15:11] [10:5] [4:0]
Word #1
Red( 1)
Green(1)
Blue( 1)
Red( 2)
Green( 2)
Blue( 2)
Word #2
Red( 3)
Green(3)
Blue( 3)
Red( 4)
Green( 4)
Blue( 4)
Word #3
Red( 5)
Green(5)
Blue( 5)
Red( 6)
Green( 6)
Blue( 6)
