S3C2440A RISC MICROPROCESSOR PWM TIMER
10-17
TIMER 2 COUNT BUFFER REGISTER & COMPARE BUFFER REGISTER (TCNTB2/TCMPB2)
Register Address R/W Description Reset Value
TCNTB2 0x51000024 R/W Timer 2 count buffer register 0x00000000
TCMPB2 0x51000028 R/W Timer 2 compare buffer register 0x00000000
TCMPB2 Bit Description Initial State
Timer 2 compare buffer register [15:0] Set compare buffer value for Timer 2 0x00000000
TCNTB2 Bit Description Initial State
Timer 2 count buffer register [15:0] Set count buffer value for Timer 2 0x00000000
TIMER 2 COUNT OBSERVATION REGISTER (TCNTO2)
Register Address R/W Description Reset Value
TCNTO2 0x5100002C R Timer 2 count observation register 0x00000000
TCNTO2 Bit Description Initial State
Timer 2 observation register [15:0] Set count observation value for Timer 2 0x00000000
