S3C2440A RISC MICROPROCESSOR

THUMB INSTRUCTION SET

4-11

FORMAT 4: ALU OPERATIONS

[2:0] Source/Destination Register

[5:3] Source Register 2

[9:6] Opcode

Figure 4-5. Format 4

OPERATION

The following instructions perform ALU operations on a Lo register pair.

NOTE

All instructions in this group set the CPSR condition codes.

Table 4-5. Summary of Format 4 Instructions

THUMB Assembler

ARM Equipment

Description

0000

AND Rd, Rs

ANDS Rd, Rd, Rs

Rd:= Rd AND Rs

0001

EOR Rd, Rs

EORS Rd, Rd, Rs

Rd:= Rd EOR Rs

0010

LSL Rd, Rs

MOVS Rd, Rd, LSL Rs

Rd := Rd << Rs

0011

LSR Rd, Rs

MOVS Rd, Rd, LSR Rs

Rd := Rd >> Rs

0100

ASR Rd, Rs

MOVS Rd, Rd, ASR Rs

Rd := Rd ASR Rs

0101

ADC Rd, Rs

ADCS Rd, Rd, Rs

Rd := Rd + Rs + C-bit

0110

SBC Rd, Rs

SBCS Rd, Rd, Rs

Rd := Rd - Rs - NOT C-bit

0111

ROR Rd, Rs

MOVS Rd, Rd, ROR Rs

Rd := Rd ROR Rs

1000

TST Rd, Rs

Set condition codes on Rd AND Rs

1001

NEG Rd, Rs

RSBS Rd, Rs, #0

Rd = - Rs

1010

CMP Rd, Rs

Set condition codes on Rd - Rs

1011

CMN Rd, Rs

Set condition codes on Rd + Rs

1100

ORR Rd, Rs

ORRS Rd, Rd, Rs

Rd := Rd OR Rs

1101

MUL Rd, Rs

MULS Rd, Rs, Rd

Rd := Rs * Rd

1110

BIC Rd, Rs

BICS Rd, Rd, Rs

Rd := Rd AND NOT Rs

1111

MVN Rd, Rs

MVNS Rd, Rs

Rd := NOT Rs
