S3C2440A RISC MICROPROCESSOR
CAMERA INTERFACE
23-22
PREVIEW DMA CONTROL REGISTER
Register Address
R/W
Description
Reset
Value
CIPRCTRL
0x4F000080
RW
Preview DMA control related
0
CIPRCTRL Bit
Description
Initial
State
RGBburst1_Pr
[23:19] Main burst length for preview RGB frames
0
RGBburst2_Pr
[18:14] Remained burst length for preview RGB frames
0
LastIRQEn_Pr [2]
0 = Normal
1 = Enable last IRQ at the end of frame capture.
(This bit is cleared automatically.)
0
NOTE: All burst lengths must be one of the 2, 4, 8, 16.
Example 1: Target image size: QCIF for RGB 32-bit format (horizontal width = 176 pixels. 1 pixel = 1 word)
176 pixel = 176 word.
176 % 16 = 0
→
main burst = 16, remained burst = 16
Example 2: Target image size: VGA for RGB 16-bit format (horizontal width = 640 pixels. 2 pixel = 1 word)
640 / 2 = 320 word
160 % 16 = 0
→
main burst = 16, remained burst = 16
PREVIEW PRE-SCALER CONTROL REGISTER 1
Register Address
R/W
Description
Reset
Value
CIPRSCPRERATIO
0x4F000084
RW
Preview pre-scaler ratio control
0
CIPRSCPRERATIO Bit
Description
Initial
State
SHfactor_Pr
[31:28]
Shift factor for preview pre-scaler
0
PreHorRatio_Pr
[22:16]
Horizontal ratio of preview pre-scaler
0
PreVerRatio_Pr
[6:0]
Vertical ratio of preview pre-scaler
0
