Page 476

SPI

S3C2440A RISC MICROPROCESSOR

22-6

SPI SPECIAL REGISTERS

SPI CONTROL REGISTER

Register Address R/W

Description

Reset

Value

SPCON0

0x59000000

R/W

SPI channel 0 control register

0x00

SPCON1

0x59000020

R/W

SPI channel 1 control register

0x00

SPCONn Bit

Description

Initial

State

SPI Mode Select

(SMOD)

[6:5]

Determine how SPTDAT is read/written
00 = polling mode

01 = interrupt mode

10 = DMA mode

11 = reserved

SCK Enable

(ENSCK)

[4]

Determine whether you want SCK enabled or not (master only).
0 = disable

1 = enable

Master/Slave

Select (MSTR)

[3]

Determine the desired mode (master or slave).
0 = slave

1 = master

Note:

In slave mode, there should be set up time for master to

initiate Tx/Rx.

Clock Polarity

Select (CPOL)

[2]

Determine an active high or active low clock.
0 = active high

1 = active low

Clock Phase

Select (CPHA)

[1]

Select one of the two fundamentally different transfer format
0 = format A

1 = format B

Tx Auto Garbage

Data mode enable

(TAGD)

[0]

Decide whether the receiving data is required or not.
0 = normal mode

1 = Tx auto garbage data mode

Note:

In normal mode, if you only want to receive data, you should

transmit dummy 0xFF data.
