USB DEVICE
S3C2440A RISC MICROPROCESSOR
13-16
END POINT OUT CONTROL STATUS REGISTER (OUT_CSR1_REG/OUT_CSR2_REG)
Register Address
R/W
Description
Reset
Value
OUT_CSR1_REG 0x52000190(L)
0x52000193(B)
R/W
(byte)
End Point out control status register1
0x00
OUT_CSR1_REG Bit MCU USB
Description
Initial
State
CLR_DATA_TOGGLE
[7]
R/W
CLEAR
When the MCU writes a 1 to this bit, the data
toggle sequence bit is reset to DATA0.
0
SENT_STALL [6]
CLEAR
/R
SET
Set by the USB when an OUT token is ended
with a STALL handshake. The USB issues a
stall handshake to the host if it sends more than
MAXP data for the OUT TOKEN.
0
SEND_STALL
[5]
R/W
R
0: The MCU clears this bit to end the STALL
condition handshake, IN PKT RDY is
cleared.
1: The MCU issues a STALL handshake to the
USB. The MCU clears this bit to end the
STALL condition handshake, IN PKT RDY
is cleared.
0
FIFO_FLUSH
[4]
R/W
CLEAR
The MCU writes a 1 to flush the FIFO.
This bit can be set only when OUT_PKT_RDY
(D0) is set. The packet due to be unloaded by
the MCU will be flushed.
0
Reserved [3:1]
-
-
-
0
OUT_PKT_RDY [0]
R/
CLEAR
SET
Set by the USB after it has loaded a packet of
data into the FIFO. Once the MCU reads the
packet from FIFO, this bit should be cleared by
MCU (write a "0").
0
