S3C2440A RISC MICROPROCESSOR
PRODUCT OVERVIEW
1-9
Table 1-1. 289-Pin FBGA Pin Assignments – Pin Number Order (Sheet 3 of 3)
Pin
Number
Pin Name
Pin
Number
Pin Name
Pin
Number
Pin Name
N1 VSSOP
R1 VD3/GPC11
U1 VDDiarm
N2 VD0/GPC8
R2 VD8/GPD0
U2 VDDiarm
N3 VD4/GPC12
R3 VD11/GPD3
U3 VSSOP
N4 VD2/GPC10
R4 VD13/GPD5
U4 VSSiarm
N5 VD10/GPD2
R5 VD18/SPICLK1/GPD10
U5 VD23/nSS0/GPD15
N6 VD15/GPD7
R6 VD21
/GPD13
U6
I2SSDO/AC_SDATA_OUT
N7 VD22/nSS1/GPD14 R7 I2SSCLK/AC_BIT_CLK
U7 VSSiarm
N8 SDCLK/GPE5
R8 SDDAT0/GPE7
U8 IICSCL/GPE14
N9 EINT8/GPG0
R9 CLKOUT0/GPH9 U9 VSSOP
N10 EINT18/nCTS1/GPG10
R10 EINT11/nSS1/GPG3 U10 VSSiarm
N11 DP0
R11
EINT14/SPIMOSI1/GPG6
U11 VDDi
N12 DN1/PDN0
R12 NCON
U12 EINT19/TCLK1/GPG11
N13 nRSTOUT/GPA21 R13 OM1
U13 EINT23/GPG15
N14 MPLLCAP
R14 AIN0
U14 DP1/PDP0
N15 VDD_RTC
R15 AIN2
U15 VSSOP
N16 VDDA_MPLL
R16 XM/AIN6
U16 Vref
N17 EINT0/GPF0
R17 VSSA_MPLL
U17 AIN1
P1 LCD_LPCREVB/GPC7
T1 VSSiarm
P2 VD5/GPC13
T2 VSSiarm
P3 VD7/GPC15
T3 VDDOP
P4 VD12/GPD4
T4 VD17/SPIMOSI1/GPD9
P5 VD14/GPD6
T5 VD19/GPD11
P6
VD20/GPD12
T6 VDDiarm
P7 I2SLRCK/AC_SYNC T7 CDCLK/AC_nRESET
P8 SDDAT2/GPE9
T8 VDDiarm
P9 SPIMOSI0/GPE12 T9 EINT9/GPG1
P10 CLKOUT1/GPH10 T10 EINT16/GPG8
P11
EINT12/LCD_PWREN/GPG4
T11 EINT21/GPG13
P12 DN0
T12 VDDOP
P13 OM2
T13 OM3
P14 VDDA_ADC
T14 VSSA_ADC
P15 AIN3
T15 OM0
P16 XP/AIN7
T16 YM/AIN4
P17 UPLLCAP
T17 YP/AIN5
