S3C2440A RISC MICROPROCESSOR CAMERA INTERFACE
23-24
PREVIEW STATUS REGISTER
Register Address R/W Description Reset Value
CIPRSTATUS 0x4F000098 R Preview path status 0
CIPRSTATUS Bit Description Initial State
OvFiCb_Pr [31] Overflow state of preview source FIFO Cb 0
OvFiCr_Pr [30] Overflow state of preview source FIFO Cr 0
FrameCnt_Pr [27:26] Frame count of preview DMA 0
FlipMd_Pr [24:23] Flip mode of preview DMA 0
ImgCptEn_PrSC [21] Image capture enable of preview path 0
IMAGE CAPTURE ENABLE REGISTER
This register must be set at last.
Register Address R/W Description Reset Value
CIIMGCPT 0x4F0000A0 RW Image capture enable command 0
CIGCTRL Bit Description Initial State
ImgCptEn [31] Camera interface global capture enable 0
ImgCptEn_CoSc [30]
Capture enable for codec scaler.
This bit must be ‘0’ in scaler bypass mode.
0
ImgCptEn_PrSc [29]
Capture enable for preview scaler
This bit must be ‘0’ in scaler bypass mode.
0
