PRODUCT OVERVIEW S3C2440A RISC MICROPROCESSOR
1-34
Table 1-4. S3C2440A Special Registers (Sheet 8 of 14)
Register
Name
Address
(B. Endian)
Address
(L. Endian)
Acc.
Unit
Read/
Write
Function
PWM Timer
TCFG0 0x51000000 ← W R/W Timer Configuration
TCFG1 0x51000004 Timer Configuration
TCON 0x51000008 Timer Control
TCNTB0 0x5100000C Timer Count Buffer 0
TCMPB0 0x51000010 Timer Compare Buffer 0
TCNTO0 0x51000014 R Timer Count Observation 0
TCNTB1 0x51000018 R/W Timer Count Buffer 1
TCMPB1 0x5100001C Timer Compare Buffer 1
TCNTO1 0x51000020 R Timer Count Observation 1
TCNTB2 0x51000024 R/W Timer Count Buffer 2
TCMPB2 0x51000028 Timer Compare Buffer 2
TCNTO2 0x5100002C R Timer Count Observation 2
TCNTB3 0x51000030 R/W Timer Count Buffer 3
TCMPB3 0x51000034 Timer Compare Buffer 3
TCNTO3 0x51000038 R Timer Count Observation 3
TCNTB4 0x5100003C R/W Timer Count Buffer 4
TCNTO4 0x51000040 R Timer Count Observation 4
