S3C2440A RISC MICROPROCESSOR USB DEVICE
13-17
Register Address R/W Description Reset Value
OUT_CSR2_REG 0x52000194(L)
0x52000197(B)
R/W
(byte)
End Point out control status register2 0x00
OUT_CSR2_REG Bit MCU USB Description Initial
State
AUTO_CLR [7] R/W R If the MCU is set, whenever the MCU reads data
from the OUT FIFO, OUT_PKT_RDY will
automatically be cleared by the logic without any
intervention from the MCU. 0
ISO [6] R/W R Determine endpoint transfer type.
0: Configures endpoint to Bulk mode.
1: Reserved. 0
OUT_DMA_INT_MAS
K [5] R/W R Determine whether the interrupt should be
issued or not.
OUT_PKT_RDY condition happens. This is only
useful for DMA mode
0 = Interrupt Enable 1 = Interrupt Disable 0
