Chapter 2 Command System RIGOL
DG1000Z Programming Guide 2-85
[:SOURce[]]:BURSt:NCYCles
Syntax [:SOURce[]]:BURSt:NCYCles {|MINimum|MAXimum}
[:SOURce[]]:BURSt:NCYCles? [MINimum|MAXimum]
Description Set the number of cycles of the N cycle burst of the specified channel.
Query the number of cycles of the N cycle burst of the specified channel.
Parameter Name Type Range Default
[] Discrete 1|2 1
Integer
1 to 1 000 000 (external or manual trigger)
1 to 500 000 (internal trigger)
1
Explanation  In the N cycle burst mode ( [:SOURce[]]:BURSt:MODE ), the signal
generator outputs the waveform with the specified number of cycles when
receiving the trigger signal.
 When [:SOURce[]] or [] is omitted, the system sets the related
parameters of CH1 by default.
Return Format The query returns the number of cycles in scientific notation with 7 effective digits,
for example, 1.000000E+01 (the number of cycles is 10).
Example :SOUR1:BURS:NCYC 10 /*Set the number of cycles of the N cycle burst of CH1
to 10*/
:SOUR1:BURS:NCYC? /*Query the number of cycles of the N cycle burst of
CH1 and the query returns 1.000000E+01*/
Related
Command
[:SOURce[]]:BURSt:MODE
[:SOURce[]]:BURSt:PHASe
Syntax [:SOURce[]]:BURSt:PHASe {|MINimum|MAXimum}
[:SOURce[]]:BURSt:PHASe? [MINimum|MAXimum]
Description Set the start phase of the burst function of the specified channel.
Query the start phase of the burst function of the specified channel.
Parameter Name Type Range Default
[] Discrete 1|2 1
Real 0° to 360° 0°
Explanation When [:SOURce[]] or [] is omitted, the system sets the related
parameters of CH1 by default.
Return Format The query returns the start phase in scientific notation with 7 effective digits, for
example, 1.000000E+01 (the start phase is 10°).
Example :SOUR1:BURS:PHAS 10 /*Set the start phase of the burst function of CH1 to
10°*/
:SOUR1:BURS:PHAS? /*Query the start phase of the burst function of CH1
and the query returns 1.000000E+01*/
