RIGOL Chapter 2 Command System
2-164 DG1000Z Programming Guide
[:SOURce[]]:SWEep:RTIMe
Syntax [:SOURce[]]:SWEep:RTIMe {|MINimum|MAXimum}
[:SOURce[]]:SWEep:RTIMe? [MINimum|MAXimum]
Description Set the return time of the sweep function of the specified channel.
Query the return time of the sweep function of the specified channel.
Parameter Name Type Range Default
[] Discrete 1|2 1
Real 0s to 500s 0s
Explanation  Return time describes the time in which the output signal returns to the “Start
frequency” from the “Stop Frequency” after the signal generator has swept from
the “Start Frequency” ( [:SOURce[]]:FREQuency:STARt ) to the “Stop
Frequency” ( [:SOURce[]]:FREQuency:STOP ) and stayed within the “Stop
Hold” ( [:SOURce[]]:SWEep:HTIMe[:STOP] ).
 When [:SOURce[]] or [] is omitted, the system sets the related
parameters of CH1 by default.
 After the “Return Time” is modified, the signal generator will output the sweep
waveform from the specified “Start Frequency”.
Return Format The query returns the return time in scientific notation with 7 effective digits, for
example, 1.000000E+00 (the return time is 1s).
Example :SOUR1:SWE:RTIM 1 /*Set the return time of the sweep function of CH1 to 1s*/
:SOUR1:SWE:RTIM? /*Query the return time of the sweep function of CH1 and
the query returns 1.000000E+00*/
Related
Commands
[:SOURce[]]:FREQuency:STARt
[:SOURce[]]:FREQuency:STOP
[:SOURce[]]:SWEep:HTIMe[:STOP]
