Fuel Delivery and Dipstick Card Option
05/29/03 15-3
DIPSTICK READINGS
To enter a dipstick reading at the Series 1000 card reader:
1. At
the ENTER CARD prompt, insert the dipstick card into the card reader. The LCD displays:
REMOVE CARD
2. Remove the card from the reader. If you are required to enter a Personal Identification
Number (PIN), the LCD displays: ENTER P.I.N.
3.
Type your PIN digits on the keypad and press ENTER (enter). If the PIN is correct, the LCD
displays: ENTER TANK #
4.
Type the number of the tank where you want to enter a dipstick reading and press ENTER.
You have three tries to select a valid tank. If after three attempts, you have not selected a
valid tank, the ENTER CARD message reappears and you must begin again at Step 1.
If you select a tank that is not available, this message appears: NO SUCH TANK!
If you select a valid tank, the LCD displays: ENTER QUANTITY.
5.
Type the dipstick reading (up to 5 digits, in whole liters only) and press ENTER. The LCD
displays QUANTITY RECORDED!.
A transaction is recorded with the tank number appearing in the P# field and the quantity
entered appearing in the QUANTITY field. The PR and ODOM fields contain zeros. The
transaction message in the ERROR field is DIPSTICK for a completed transaction and
INVALID TANK for an error transaction.
Example:
UEVAÂ!"#$Â
Â
VT7PÂ97T@ÂAIRÂÂXADÂÂ@7VAÂÂÂÂÂVEIAÂÂRÆÂRTÂSW7PVEVaÂÂQ@QIÂÂÂATTQTÂ
!" )Â)))# %(Â'% )Â)" !"#Â!#0$  ! ÂÂÂ!(% Â@ERUVE9GÂ
