CDM-570A/570AL Satellite Modem with Optional Packet Processor MN-CDM570A
Ethernet-based Remote Product Management Revision 2
7–8
7.4 CDM-570A HTTP (Web Server) Interface
A user-supplied Web browser allows the full monitoring and control (M&C) of the CDM-
570A/570AL from its HTTP Interface. This non-secure embedded Web application is designed
for, and works best with, Microsoft Internet Explorer Version 7.0 or higher.
7.4.1 Operational Features
7.4.1.1 User Login
Type the CDM-570A/570AL Ethernet Traffic IP Address (shown in this example as
http://192.168.1.11) into the Address area of the user PC Web browser:
The login window, similar to the example shown here, opens.
Enter the assigned User Name and Password. The CDM-570A
HTTP Interface default user names and passwords are as
follows:
• Admin comtech/comtech
• Read/Write opcenter/1234
• Read-only monitor/1234
HTTP Login User Access Levels are further defined as follows:
Admin User Read/Write User read-only User
Full Access to all web
pages
No Access to Admin pages No Access to Admin pages
Full Access for all other web pages View Only Access for all other web pages
If login is attempted and remote control is set to either Local or Remote mode,
access is prohibited and the following error message displays in the browser
window:
To properly access the CDM-570A HTTP Interface, configure remote control access
for the unit to Ethernet mode. Click [Enable Ethernet Mode].
Alternately, from the CDM-570A/570AL front panel, use the ◄ ► and ▲ ▼ arrow keys to first
navigate to the remote control configuration menu, and then select Ethernet mode (press ENTER
when done):
SELECT: CONFIG ► Rem ► Ethernet
