Table 11-5: Accept Status Code Values
Bit Decimal Binary Values Fault
0 1 00000000 00000000 00000000 00000001 CURRENTRMS_HI
1 2 00000000 00000000 00000000 00000010 CURRENTRMS_LOW
2 4 00000000 00000000 00000000 00000100 CURRENTPEAK_HI
3 8 00000000 00000000 00000000 00001000 CURRENTPEAK_LOW
4 16 00000000 00000000 00000000 00010000 VOLTAGERMS_HI
5 32 00000000 00000000 00000000 00100000 VOLTAGERMS_LOW
6 64 00000000 00000000 00000000 01000000 VOLTAGEPEAK_HI
7 128 00000000 00000000 00000000 10000000 VOLTAGEPEAK_LOW
8 256 00000000 00000000 00000001 00000000 FORCE_HI
9 512 00000000 00000000 00000010 00000000 FORCE_LOW
10 1024 00000000 00000000 00000100 00000000 CONDANGLE_HI
11 2048 00000000 00000000 00001000 00000000 CONDANGLE_LOW
12 4096 00000000 00000000 00010000 00000000 SETDOWN_HI
13 8192 00000000 00000000 00100000 00000000 SETDOWN_LOW
14 16384 00000000 00000000 01000000 00000000 EXPANSION_HI
15 32768 00000000 00000000 10000000 00000000 EXPANSION_LOW
16 65536 00000000 00000001 00000000 00000000 INITTHICK_HI
17 131072 00000000 00000010 00000000 00000000 INITTHICK_LOW
18 262144 00000000 00000100 00000000 00000000 FINALTHICK_HI
19 524288 00000000 00001000 00000000 00000000 FINALTHICK_LOW
20 1048576 00000000 00010000 00000000 00000000 RESISTANCE_HI
21 2097152 00000000 00100000 00000000 00000000 RESISTANCE_LOW
22 4194304 00000000 01000000 00000000 00000000 ENERGY_HI
23 8388608 00000000 10000000 00000000 00000000 ENERGY_LOW
24 16777216 00000001 00000000 00000000 00000000 POWER_FACTOR HI
25 33554432 00000010 00000000 00000000 00000000 POWER_FACTOR LOW
26 67108864 00000100 00000000 00000000 00000000 HCYCLE_CNT_LOW
27 134217728 00001000 00000000 00000000 00000000 HCYCLE_CNT_HI
28 268435456 00010000 00000000 00000000 00000000 Not used
29 536870912 00100000 00000000 00000000 00000000 Not used
30 1073741824 01000000 00000000 00000000 00000000 SEGMENT_TOLERANCE_ERROR
31 -2147483648 10000000 00000000 00000000 00000000 MISSING RECORDS
