Rockwell Automation Publication GMSI10-UM002D-EN-E - August 2012 99
Loading and Unloading Chapter 3
3. The Current column shows the word ‘Yes’ for the current data collector.
To make the Enpac 2500 the current data collector, move to the Current
column for the Enpac 2500. Press Enter or double-click in the column to
change the word from ‘No’ to ‘Yes.’ The previously selected data collector
automatically changes to ‘No.’
4. Move to the Baud column in the Enpac 2500 row and set the Baud rate to
the same baud rate you select in the Enpac 2500.
Refer to Set Up the Data Collector for Communication on page 102 .
5. Move to the Protocol column and set the Protocol to ‘N81.’
6. Click Advanced if you want to change the data/route display and some of
the data collection characteristics of the Enpac 2500. You can also select a
different version of the data collector operating system.
The Data Collector Advanced Settings dialog appears.
See Data Collector Advanced Settings Parameters on page 100 for a
description of the parameters.
7. Click OK to close the Data Collector Advanced Settings dialog.
TIP You must log in with a Supervisor- or Administrator-level user name
and password to make any changes to these data collector settings.
IMPORTANT Changing the configuration options for the data collector may prevent
Emonitor from communicating with the data collector, or may cause the
data collector to malfunction. Make sure you understand a configuration
option before you change it.
