22 Rockwell Automation Publication GMSI10-UM002D-EN-E - August 2012
Chapter 1 The Enpac 2500 Data Collector
Right Arrow • Displays the next screen of information if there is more than one screen (for example,
selecting a point in the Data Collection screen).
• Opens the menu selection on the Setup and Instrument Configuration screens.
• Moves the signature cursor to the right.
ON/OFF The ON/OFF key turns the data collector on and off. To turn the data collector off, press and
hold the ON/OFF key for one second.
Numeric The numeric keys allow you to enter numeric values or move to the appropriate menu
selection on the Main Menu screen.
Decimal The Decimal (.) key allows you check the status of the battery, or enter a decimal point in a
numeric field.
Refer to Checking Battery Life on page 27 for more information.
+/- The +/- key allows you to expand or compress a signature plot on the screen.
0 The 0 key acts as a `Shift‘ key that has multiple uses depending on the current operation.
• In a Setup screen numeric input field, the key acts as a zero.
• In Setup screens, the key moves the selection to the first parameter when you are not
in an input field.
• In all other screens, pressing and holding the key displays alternate functions for the
function keys.
Table 2 - Key Definitions
Keys Definition
