Preface
Organization
To help you navigate through this manual, it is organized in chapters based on
these tasks and topics.
Document Conventions
There are several document conventions used in this manual, including the
following:
• The Enpac 2500 is referred to as Enpac, instrument, unit, or data collector
throughout this manual.
• The different versions of Emonitor (Enshare®, Odyssey Deluxe, and
Odyssey Basic) are referred to as Emonitor throughout this manual.
• Emonitor uses the term ‘list’ for an ordered set of measurement
definitions. The Enpac uses the term ‘route’ to refer to a list loaded in the
Enpac. This manual uses the two terms interchangeably.
Section Description
Preface Contains an overview of the manual.
Chapter 1, The Enpac 2500 Describes the Enpac 2500 data collector and covers the basic operations
and configuration of the data collector.
Chapter 2, Setting up Measurements Describes setting up measurement definitions in Emonitor for use with
the data collector. It also explains lists, inspection codes, and alarms.
Chapter 3, Loading and Unloading Describes loading lists and unloading data.
Chapter 4, Collecting and Reviewing Data Describes the tasks associated with collecting data including list data.
Chapter 5, Multi-channel Measurements Shows you how to set up and collect dual channel, cross channel phase,
and orbit measurements.
Chapter 6, Balancing Application Describes methods used for performing one- or two-plane balancing by
using the data collector coupled with a speed measuring device.
Chapter 7, Time Recording Application Describes how to set up and collect time recording measurements.
Chapter 8, Bump Test Application Describes the tasks needed to set up and collect bump test
measurements.
Chapter 9, Run Up/Coast Down Application Describes recording and analyzing run up/coast down measurements.
Chapter 10, FRF Frequency Response
Function Extension Module Describes how to determine the natural frequencies where resonances
occur, as well as capturing data about the frequency response of the
structure being tested.
Appendix A, Specifications Lists the technical specifications for the Enpac 2500 data collector.
Appendix B, Frequently Asked Questions Contains answers to frequently asked questions.
Appendix C, Accessories Provides a current list of accessories available for the Enpac 2500 data
collector. For definitions of terms used in this Guide.
Glossary Definitions of terms.
