Rockwell Automation Publication GMSI10-UM002D-EN-E - August 2012 301
Appendix
A
Specifications
Appendix A lists the technical specifications for the Enpac 2500.
Enpac 2500 Technical Specifications
Product Feature Specification
Enclosure
Size
Weight
Case
Display
186 x 93 mm (narrowest point)
186 x 134 mm (widest point)
715 g (1.52 lbs)
Material: 80% ABS & 20% polycarbonate plastic
Hand strap fixing either side of unit.
LCD, Backlit Color
1/4 VGA (240 x 320) 58 x 77 mm viewable
Connector
PC Comms
Signal Input
Other I/O
RS-232 - 9-way D Type (Plug)
USB Client
IrDA (not currently supported)
Channel 1 6-pin Fischer
3xICP/AC/DC
Channel 2 6-pin Fischer
ICP/AC/DC
7-pin Fischer Trigger in, Trigger tachometer supply out,
Power in/battery charge, USB
System
Operating System
Processors
Memory
Memory available for user date
PC Card Support
Status Indicators
Microsoft Windows® CE
Main XScale PXA255 @ 400 MHz, DSP Motorola
DSP56L307
64 MB (total)
>40 MB Flash (Max 50 MB)
Type I or II PCMCIA card, MCC/SD card
Red, Green, Amber
