Collecting and Reviewing Data
Chapter 4
Capturing Screens
You can capture Enpac 2500 data collector screen images in a bitmap (.bmp)
format and store them on the PCMCIA memory card.
Follow these steps to capture an image to an PCMCIA memory card.
1.
Display the screen that you want to capture.
2.
Press the 0 key and the 7 key.
The Print dialog box appears.
3.
Press F2 (OK) to store the image in a.bmp format on the storage card.
The Enpac 2500 data collector stores the image in: \Storage Card\dumpn
where ‘n is the number of the bitmap. This number gets incremented by
one each time you store an image on the card.
4.
Press F4 (OK) to return to the screen.
Print Reports and Plots by Using the Emonitor Software
You can use the Emonitor software to print reports.
MONTR-UM001
.
