58 Rockwell Automation Publication GMSI10-UM002D-EN-E - August 2012
Chapter 1 The Enpac 2500 Data Collector
Follow these steps to replace the battery.
1. Using a flat head screwdriver, remove the two latch screws on the battery
access panel.
2. Remove the battery access panel.
3. Press the Reset button using a 1/16th inch diameter pin or a straightened
paper clip.
4. Replace the battery access panel and tighten the two screws.
The Enpac 2500 data collector automatically powers on.
Allow at least thirty seconds for the instrument to reconfigure and activate the
display after the Instrument Setup screen appears.
IMPORTANT A hardware reset can also initiate the Engineer Mode Menu.
See Engineer Mode Menu Screen on page 37 for more information.
IMPORTANT The current date, time and some status information will be lost, and
the backlight setting will be returned to the default setting following a
hardware reset.
See Set the Date, Time, and Date Format on page 32 for more
information.
IMPORTANT Any data held in internal memory is secure and will not be lost nor
destroyed during a hardware reset.
