Rockwell Automation Publication GMSI10-UM002D-EN-E - August 2012 121
Collecting and Reviewing Data Chapter 4
Collecting Route Data This section explains how to collect list (route) data using the Enpac 2500 data
collector. Using your predictive maintenance software, you can load a list to the
data collector to organize your data collection, then collect data for the
measurement definitions in the list (route). Once you have prepared the
instrument for data collection you are ready to select a route and collect data
.
Select a Route
The Enpac 2500 Data Collection program operates on a route. This can be the
Default Route or a route you create and unload with your computer software.
Routes that you create with your computer software may contain multiple points,
and each point may cause the instrument to perform multiple measurements.
Follow these steps to select a route.
1. Select Data Collection from the Main Menu and press Enter.
2. Select a route from the Route Manager screen and press Enter.
TIP If you do not use the predictive maintenance software to create and load
lists to the data collector, Enpac 2500 data collector automatically creates a
route named Default Route for you to use to collect data.
TIP If the data collector does not have a route downloaded from the
Emonitor software, it lets you create a default route. The default route
contains only one measurement point.
Once you have selected a route, you can
open the route by pressing Enter or the
Right arrow.
