42 Rockwell Automation Publication GMSI10-UM002D-EN-E - August 2012
Chapter 1 The Enpac 2500 Data Collector
Configure the Data Collection Options
The data collection options affect the measurement, the data collection process,
and how the data displays on the Enpac 2500. The instrument stores the data
collection settings even when the instrument is powered off. However, you
should check these options each time you start data collection.
Follow these steps to download a Route onto the data collector by using the
Emonitor software.
1. Using the Route Manager, select an appropriate route and press Enter.
The Data Collection screen appears.
2. Press 0 (Shift) to display the Config function.
Bias Check The bias of the transducer before taking the measurement. Manual (default)
Automatic
Module ICP The Module ICP option allows the manual control of turning off/on ICP power to
transducers in application modules. Never
Always
Auto
Language Sets the language for the user interface. Chinese
English
Francais
Deutsch
Italiano
Portuguese (Brasil)
Russkiy
Espanol (Spain, traditional)
Table 7 - Setup Screen Parameter Descriptions
Parameter Description Value
