I
NDEX
Alarm configuration ............ 190
All Chan save/recall
description ........................... 93
Battery disposal .................... 243
Battery replacement ............. 243
Baud rate configuration ....... 196
Brightness & contrast ........... 185
Calibration ............................. 245
Calibration key ....................... 19
CC vrange mode description 81
CC+CV mode ......................... 69
Channel configuration
CC voltage range ................. 165
Go/NoGo mode .................. 177
Go/NoGo On/Off .............. 179
Independent setting ............ 171
Load delay time ................... 173
Protection All Clear ............ 165
SPEC test ON/OFF ............. 179
Step resolution ..................... 175
Channel configuration
Configuration menu ........... 161
OCP/OCV/OPP ................. 162
Channel configuration
Von voltage configuration . 167
Channel configuration
Short ...................................... 168
Channel configuration
channel control .................... 170
Channel control configuration170, 235
Channel control connection .. 56
Channel control description .. 85
Channel control mode
description ........................... 83
Channel duration time
settings mode description . 77
Cleaning the instrument .......... 7
Clear key .................................. 19
Configuration mode
description ........................... 79
Connection
Channel control ..................... 56
Frame link .............................. 54
Go/NoGo control .................. 59
Remote sense.......................... 48
Wire gauge ............................. 44
Wire Inductance .................... 44
Connection procedure ........... 46
Constant Resistance mode
description ........................... 65
Constant voltage + constant
current mode description .. 69
Constant voltage mode
description ........................... 68
Date and time configuration 183
Default Settings .................... 251
Delay time mode description 84
Dimensions ............................ 261
Display key .............................. 29
Display settings .................... 185
Disposal instructions ............... 8
Dynamic constant current
mode description ................ 62
Dynamic loads Constant
Resistance mode description66
EC Declaration of Conformity263
EN61010
measurement category ........... 6
Pollution degree ...................... 8
