PEL-2000 Series User Manual
14
PEL-2020 PEL-2040
DC Electronic Load PEL-2002
PEL-2040
DC Electronic Load
70A / 80V , 350W PEL-2020
DC Electronic Load
L R 20A / 80V , 100W 20A / 80V , 100W
P8 P7 P9
P5 P4 P6
P2 P1 P3
LOCK P0
HELP
6 5 4
0
1 2
CLEAR
3
7 8
CHAN
9
LOAD
FUNC FILE
F1
ENTER
PRESET SHIFT
OFF ON /
F2 F3 F4 F5
CAL.
UTILITY LOCAL
80V DC MAX
MAX 80V DC
V sense
LOAD
DISPLAY SHORT
STATIC/ DYNA. A / B R / L DYNA. STATIC/
SHORT DISPLAY
LOAD
L
V sense V sense
R
80V DC MAX 80V DC MAX
L 80V DC MAX MAX 80V DC R
The 4 different load module models each differ in the amount of current,
voltage and power and the amount of channels that the load module
can accommodate. The procedures in this manual will be load module
model independent unless specifically stated. Below is a table showing
the basic differences between each load module model. For detailed
specifications, please see page 253.
Load Module Channels Power (W)
CH L/R
Current (A)
Range
Low/High
Voltage (V)
PEL-2020
(100Wx2)
2 100/100 2/20 1-80
PEL-2030
(30/250W)
2 30/250 5/4/40 1-80
PEL-2040 1 350 7/70 1-80
PEL-2041 1 350 1/10 2.5-500
