OPERATION
155
Channel Duration Time Settings
Background Each sequence can have the timing duration data
of another sequence. For example CH1’s sequence
can import the timing duration settings of CH2’s
sequence.
This is useful to quickly compare two different
loads to the same timing characteristics. See page
74 for more details.
Each channel’s sequence can be turned off by
configuring the channel Setting to OFF. If a
channel uses the same channel number, i.e CH 01

01, then the duration time settings will not be
altered for that channel.
One channel must output a Trigger Sequence
Signal via PIN4 of the frame link connector if a
sequence is run. For more details see page 74.
Any channels with channel control (CH CONT) set
to external will be shown on the right side as EXT.
Parameter CH 01~08 Range OFF ~ maximum channels
TRIG OUT
Ensure at least one sequence has been created and
saved. Page 151
Panel operation 1. Press FUNC, then Sequence (F2)
to enter the Channel Duration
Time menu.
