OPERATION
135
Editing CV Parameters
Background Constant Voltage mode can be set to a maximum
limit (Curr Limit). Using the current limit enables
limiting the current draw.
When using CV mode on single channel load
modules, two voltage levels can be sunk, A Value
and B Value. On a dual channel load module, only
one voltage level can be sunk per channel: A
Value.
Ensure the menu is in CV Mode. See page 134.
Parameters A Value 0~rating V
B Value 0~rating V
Curr Limit Load module dependent
Panel Operation 1. Use the Selector knob to
highlight A Value.
