PEL-2030 (30W/250W)
CHANNELS 2
CHANNEL Left Right Right
RANGE N/A Low High
POWER 30W 250W 250W
CURRENT 0~5A 0~4A 0~40A
VOLTAGE 1~80V
MIN.OPERATING
VOLTAGE(dc) 1.0V at 5A 1.0V at 4A 1.0V at 40A
STATIC MODE
CONSTANT CURRENT MODE
Range
0~5A 0~4A 0~40A
Resolution 1mA 1mA 10mA
Accuracy ±(0.1%set +
0.1%F.S)
±(0.1%set +
0.1%F.S)
±(0.1%set +
0.2%F.S)
CONSTANT RESISTANCE MODE
Range
0.3Ω~1.2KΩ
(30W/16V)
15Ω~60KΩ
(30W/80V)
0.0375Ω~150Ω(250W/16V)
1.875Ω~7.5KΩ(250W/80V)
Resolution 12bits
Accuracy 12KΩ : ±
(0.2%set(
℧) + 0.1℧)
60K
Ω: ±
(0.1%set(
℧) +
0.02
℧) with ≥ 2.5V
at input
150Ω : ±(0.2%set(
℧) + 0.1℧)
7.5KΩ: ±(0.1%set(
℧) + 0.02℧) with
≥ 2.5V at input
CONSTANT VOLTAGE MODE
Range
1~80V
Resolution 20mV
Accuracy ±(0.05%set + 0.1%F.S.)
Range 0~5A 0~40A
Resolution 1mA 10mA
Accuracy ±(0.1%set +
0.1%F.S.)
±(0.1%set + 0.2%F.S.)
