Nterface – GW Instek PEL-2000 Series User Manual User Manual
Page 232
PEL-2000 Series User Manual
232
I
NTERFACE
The Interface chapter details the pin configuration of the RS232,
GPIB, Frame Link, Channel Control and Go/NoGo interfaces.
Interface Configuration .................................................. 233
Configure RS-232C interface ............... 233
Configure GPIB interface .................... 234
Configure Channel Control interface .. 235
Configure Frame Link Interface .......... 236
Configure Go/NoGo Interface ............ 239
USB Interface Connection .................. 240
