PEL-2000 Series User Manual

222

03/02/09

10 : 30

Configure

Save

CC

Dyna

High

CH1

Media

USB

File

Utility

File

The screen updates to show Save Folder. Note it is not
possible to recall all presets at once, only save.

7. Use the Selector Knob to edit

Save Folder.

8. Choose a directory name

(ALL0000~ALL0099).

Note

Any used directories will not be available. It is not
possible to over- write older directories. They must be
deleted first.

9. Press F3 (Save)

10. A screen message will be

displayed when the save is
complete.

Save/Recall Preset
(current channel)

11. Use the Selector Knob to edit

Save Chan and Data Type.

12. Choose Current and Preset.
