AFG-2225 Series User Manual
88
6. Press F1~F5 to select the
frequency range.
uz

~
z

Range Waveform Carrier Frequency
Sine wave 1μHz~25MHz
Square wave 1μHz~15MHz
Ramp wave 1μHz~1MHz
Pulse wave 500μHz~15MHz
Default frequency 100Hz
FSK Rate
FSK Rate function is used to determine rate at which the output
frequency changes between the carrier and hop frequencies. The
FSK Rate function only applies to internal FSK sources.
Panel Operation 1. Select the MOD key.

2. Press F3 (FSK).
K 
3. Press F3 (FSK Rate).
Kat 
4. The FSK Rate parameter will become
highlighted in the waveform display area.
