AFG-2225 Series User Manual
78
Square 1μHz~15MHz
Ramp 1μHz~1MHz
Default frequency 1kHz
FM Wave Shape
The function generator can accept internal as well as external
sources. The AFG-2225 has sine, square, triangle, positive and
negative ramps (UpRamp, DnRamp) as the internal modulating
waveform shapes. Sine is the default wave shape.
Background 1. Select MOD.

2. Press F2 (FM).
 
3. Press F4 (Shape).
hap 
4. Press F1 ~ F5 to select the
waveform shape.
n

~
namp

5. Press Return to return to the
previous menu.
Return
Range Square wave 50% Duty cycle
UpRamp 100% Symmetry
Triangle 50% Symmetry
DnRamp 0% Symmetry
