AFG-2225 Series User Manual
260
Arbitrary Waveform Commands
Arbitrary Waveform Overview
Use the steps below to output an arbitrary waveform over the
remote interface.
Output Arbitrary
Waveform
Select Waveform
Frequency,
amplitude and
offset
Load Waveform
Data
Set Waveform
Rate
1. Use the SOURce[1|2]:FUNCtion USER
command to output the arbitrary waveform
currently selected in memory.
2. Use the APPLy command to select frequency,
amplitude and DC offset. Alternatively, the
FUNC, FREQ, AMPl, and DCOffs commands
can be used.
3. Waveform data (1 to 4096 points per
waveform) can be downloaded into volatile
memory using the DATA:DAC command.
Binary integer or decimal integer values in the
range of ± 511 can be used.
4. The waveform rate is the product of the
number of points in the waveform and the
waveform frequency.
Rate = Hz × # points
Range:
Rate: 120MHz
Frequency: 60MHz
# points:
1~4096
