AFG-2225 Series User Manual
54
O
PERATION
The Operation chapter shows how to output basic waveform
functions. For details on modulation, sweep, burst and arbitrary
waveforms, please see the Modulation and Arbitrary waveform
chapters on pages 64 and 147.
Select a Waveform ............................................................. 55
Sine Wave ............................................................................. 55
Square Wave ........................................................................ 56
Setting the Pulse Width ....................................................... 57
Setting a Ramp Waveform ................................................... 58
Selecting a Noise Waveform ................................................ 59
Setting the Frequency .......................................................... 60
Setting the Amplitude .......................................................... 62
Setting the DC Offset ........................................................... 63
