-222 Data out of range; burst period limited by length of burst; value
clipped to upper limit
Example: The burst period must be greater than
burst count divided by the frequency + 200 ns. The
burst period is adjusted to satisfy these conditions.
burst period > 200 ns + (burst count/burst
frequency).
-222 Data out of range; burst count limited by length of burst; value
clipped to lower limit
Example: The burst count must be less than burst
period * the waveform frequency when the the
trigger source is set to immediate (SOURce[1|2]:
TRIG:SOUR IMM). The burst count is automatically
set to the lower limit.
-222 Data out of range;amplitude; value clipped to ...
Example: If the amplitude was set to a value out of
range, it is automatically set to an upper or lower
limit.
-222 Data out of range;offset; value clipped to ...
Example: If the offset was set to a value out of range,
it is automatically set to an upper or lower limit.
-222 Data out of range;frequency in burst mode; value clipped to ...
Example: If the frequency was set to a value out of
range in burst mode. The burst frequency is
automatically set to an upper or lower limit, taking
the burst period into account.
-222 Data out of range;frequency in FM; value clipped to ...
Example: The carrier frequency is limited by the
frequency deviation (SOURce[1|2]: FM:DEV). The
carrier frequency is automatically adjusted to be less
than or equal to the frequency deviation.
