AFG-2225 Series User Manual
136
System and Settings
There are a number of miscellaneous settings and firmware settings
that can be configured.
Viewing and Updating the Firmware
View Version 1. Press the UTIL key.

2. Press F2 (Cal.).
al 
3. Press F2 (Software).
oftwar 
4. Press F1 (Version) to view the
firmware version.
rson 
The version information will be shown on screen:
Instrument, Version, FPGA Revision
Update Firmware 5. To update the firmware,
insert a USB flash drive with
a firmware file in the USB
host drive. Press F2
(Upgrade).
prad 
Note
The firmware file (*.bin) must be located in a
directory, directly off the USB root directory.
