AFG-2225 Series User Manual
146
DSO Link
Background DSO Link enables the AFG-2225 to receive lossless
data from a GDS-2000 Series DSO to create ARB
data.
1. Connect the AFG-2225 USB
host port to the GDS-2000’s
USB B device port.
→
Panel Operation 2. Press the CH1/CH2 key.
CH1/CH2
3. Press F5 (DSO Link).
nk 
4. Press F1 (Search).
arh 
5. To select a DSO channel,
Press F2 (CH1), F3 (CH2), F4
(CH3) or F5 (CH4). The
acquired data can then be
displayed.


~


