AFG-2225 Series User Manual
204
-4.99V~4.99V (50Ω)
Example SOUR1:APPL:PULS 1KHZ,MIN,MAX
Sets frequency to 1kHz and sets the amplitude to
minimum and the and offset to the maximum.
SOURce[1|2]:APPLy:NOISe
Source Specific
Command
Description Outputs Gaussian noise. Amplitude and offset can
also be set.
Note Frequency cannot be used with the noise function;
however a value (or DEFault) must be specified.
The frequency is remembered for the next function
used.
Syntax SOURce[1|2]:APPLy:NOISe [
[, [,] ]]
Parameter Not applicable
1mVpp~10Vpp (50Ω)
-4.99V~4.99V (50Ω)
Example SOUR1:APPL:NOIS DEF, 3.0, 1.0
Sets the amplitude to 3 volts with an offset of 1
volt.
SOURce[1|2]:APPLy:USER
Source Specific
Command
Description Outputs an arbitrary waveform from the selected
channel. The output is that specified from the
FUNC:USER command.
Note Frequency and amplitude cannot be used with the
DC function; however a value (or DEFault) must
be specified. The values are remembered for the
next function used.
