AFG-2225 Series User Manual
250
The following is an overview of the steps required to generate a
burst waveform.
Enable Burst
Mode
Configuration
Choose
Triggered/Gated
Mode
Set Burst Count
Set the burst
period
Set Burst Starting
Phase
Select the trigger
1. Turn on Burst mode using the
SOURce[1|2]:BURS:STAT ON command.
2. Use the APPLy command to select a sine,
square, ramp, pulse burst waveform*.
Alternatively, the FUNC, FREQ, AMPl, and
DCOffs commands can be used to create the
burst waveform* with a designated frequency,
amplitude and offset.
*2 mHz minimum for internally triggered
bursts.
3. Use the SOURce[1|2]: BURS:MODE
command to select from triggered or gated
burst modes.
4. Use the SOURce[1|2]:BURS:NCYC command
to set the burst count. This command is only
for triggered burst mode only.
5. Use the SOURce[1|2]:BURS:INT:PER
command to set the burst period/cycle. This
command is only applicable for triggered
burst mode (internal trigger).
6. Use the SOURce[1|2]:BURS:PHAS command
to set the burst starting phase.
7. Use the SOURce[1|2]:BURS:TRIG:SOUR
command to select the trigger source for
triggered burst mode only.
