AFG-2225 Series User Manual
30
10. Press the output key.
OUTPUT
FM
Example: FM modulation. 100Hz modulating square wave. 1kHz
Sine wave carrier. 100 Hz frequency deviation. Internal Source.
Output:
50 Ω
CH1
1. Press the MOD key
and select FM (F2).
 
2. Press Waveform and
select Sine (F1).
 n
Input: N/A 3. Press the Freq/Rate
key, followed by 1 +
kHz (F4).
/  kz
4. Press the MOD key,
select FM (F2), Shape
(F4), Square (F2).
  hap
quar
5. Press the MOD key,
select FM (F2), FM
Freq (F3).
  rq
6. Press 1 + 0 + 0 + Hz
(F2).
  
z
7. Press the MOD key,
select FM (F2), Freq
Dev (F2).
  rqv
8. Press 1 + 0 + 0 + Hz
(F3).
   z
